Yoghurt Bottle Filling Machines

Product Overview

Drinking yoghurt is available as plain, flavoured and fruit-based products, with the formulation affecting product consistency and filling behaviour. Fruit-based yoghurt can also contain real fruit pieces or other inclusions, which require the filling system to accommodate the product structure while maintaining consistent product flow.

The filling machine should therefore match the product formulation as well as the required production capacity. Standard drinking yoghurt applications can use conventional volumetric dosing, while products with inclusions may require a different dosing configuration.

Filling System

Volumetric piston filling provides the standard solution for drinking yoghurt and suits a wide range of plain and flavoured products. The piston system gives controlled volumetric dosing and can accommodate the viscosity of typical drinking yoghurt applications.

For applications requiring higher fill-weight accuracy, net weight filling provides an alternative dosing method. Where fruit pieces or other inclusions form part of the product, the dosing system may also require suitable valves and an enlarged product path to maintain reliable product flow.

Packaging

Drinking yoghurt is mainly packed in PET bottles, with HDPE also used for some products and markets. Retail formats typically range up to around 1 litre, while single-serve formats up to approximately 500 ml are particularly common.

Bottle size and design should match the intended serving format and filling line requirements. The bottle opening and handling characteristics also need to suit the product and selected filling equipment.

Standard Machine Configuration

Bottle filling equipment selection normally starts with four key factors: required output, bottle format, available floor space and hygiene requirements. Establishing these parameters early helps narrow the choice between semi-automatic, linear and monobloc filling systems.

For lower production volumes, a semi-automatic filling machine can provide a practical solution where manual bottle handling remains acceptable. Automatic linear filling machines provide a balance between production output, flexibility and floor space requirements, making them suitable for a wide range of bottling applications. Where higher outputs are required within a compact footprint, a monobloc system can combine multiple packaging operations, such as bottle rinsing, filling and capping, within a single machine platform.

Bottle geometry, closure type, filling accuracy requirements and the desired level of automation also influence machine design and downstream equipment selection.

Optional Equipment

Semi-automatic filling machines are often combined with handheld capping equipment where a simple and cost-effective packaging solution is sufficient. Automatic filling systems can form part of a fully automatic bottling line incorporating bottle handling, capping, labelling, coding and group packaging equipment.

Bottle handling equipment supports the continuous flow of bottles through the packaging line. Depending on the required production output and level of automation, this may include rotary feeding tables, bottle unscramblers and conveyor systems. Rotary feeding tables provide a simple method of bottle accumulation and feeding, while bottle unscramblers automatically orient and transfer bottles onto the conveyor system. As production output increases, bottle unscramblers help maintain a consistent bottle supply while reducing manual handling.

Conveyor selection depends on the bottle design and overall line layout. Table-top chain conveyors are commonly used to transport filled bottles and can accommodate both straight and curved line configurations. Air conveyors are typically used where bottles can be supported by the neck finish and are most commonly applied for empty PET bottle transport before filling.

Applications with higher hygiene requirements may justify additional measures such as bottle rinsing systems, cap treatment modules or Ultra-Clean filling configurations. Bottle rinsing systems are commonly used where additional hygienic control is required before filling. Ultra-Clean systems typically incorporate HEPA-filtered air management and controlled overpressure within the filling area to reduce the risk of product contamination. Product protection requirements may also justify additional options such as inert gas flushing.
